Acuity MEMS Pressure Sensors



Very Low Pressure Sensor AC3050 Die
 AC4080 Amplifed Pressure Sensor
Low Pressure AC3030 Wafer

Acuity Products:

    Acuity Sensor Die

    Medium Pressure (5 PSI to 300 PSI - 0.35 bar to 20 bar)

    Part
    Die
    Pressure Ranges (PSI)
    Typical Output
    Features
    5
    15
    30
    50
    100
    150
    300

    AC3010

    3.6 kohm

    AC3010 Series Die
    X
    X
    X
    X
    X
    X
    X
    125 mV
    		 • 3.6 kohm bridge impedance
    • Available in Gauge or Absolute

    • 5 to 300 PSI Full-Scale Ranges

    • 1.6 X 1.8 mm Die
    • High Accuracy, High Zero Stability

    AC3012

    5 kohm
    AC3012 Pad Layout
    X
    X
    X
    X
    X
    X
    X
    125 mV
    		• 5.0 kohm bridge impedance
    • Available in Gauge or Absolute

    • 5 to 300 PSI Full-Scale Ranges

    • 1.6 X 1.8 mm Die
    • High Accuracy, High Zero Stability
        X = Planned Ranges





    Low Pressure (0.015 to 7.5 PSI - 1 mbar to 500 mbar)

    Part
    Die
    Pressure Ranges (mBar)
    Typical Output
    Features
    1.0
    2.5
    		5.0
    10
    20
    50
    100
    200
    500
    AC3030 Die
    X
    X
    X
    X
    x
    50 mV

    • 20 to 500 mBar Full-Scale Ranges

    • 1.6 X 1.6 mm Die
    • High Accuracy, High Zero Stability
    AC3031 Die
    X
    X
    50 mV
    		 • Identical to the AC3030 in performance but with a metal pattern that allows all wirebonds to be done on one side.
    • 20 and 50 mBar Full-Scale Ranges, standard.
    • High Accuracy, High Zero Stability
    AC3050 Die
    X
    50 mV

    • 10 mBar Full-Scale Range
    • 1.9 X 1.9 mm Die
    • High Accuracy, High Zero Stability
    AC3055 Die
    X
    X
    45 mV
    		• 10 mBar Full-Scale Range
    • 1.9 X 1.9 mm Die
    • High Accuracy, High Zero Stability with enhanced linearity over AC3050

    AC3070

    NEW!!!
    AC3070 Die
    X
    X
    18 mV
    		• 2 and 1 mBar Full-Scale Range
    • 2.4 X 2.4 mm Die

    • High Accuracy, High Zero Stability
        X = Available Ranges

    Acuity Packaged Sensor

    Part
    Package
    Pressure Ranges (mBar)
    Typical Output
    Features
    1.0
    2.5
    5.0
    10
    20
    50
    100
    200
    500
    AC4010

    NEW!!! AC4010-1P0
    AC4010 - Uncompensated Low Pressure Sensor
    S

    S
    S
    S
    S
    X
    X
    50 mV
    		Unamplified, basic sensor die in SIP Package. Now extended down to 1 mbar.
    AC4020
    AC4020 - Compensated Low Pressure Sensor

    S
    X
    X
    X
    50 mV
    		Unamplified, temperature-compensated and calibrated sensor in DIP Package for current excitation
    AC4022
    AC4020 - Compensated Low Pressure Sensor

    S
    X
    X
    X
    25 mV
    		Unamplified, temperature-compensated and calibrated sensor in DIP Package for voltage excitation
    AC4065

    NEW!!! AC4065-1P0
    AC4065 - Amplifed Low Pressure Sensor
    S
    X
    S
    S
    X
    X
    X
    X
    X
    4.0 V
    		Amplified, calibrated with correction of 2nd order sensor error; provided with I2C and Analog outputs. Now extended down to 1 mbar.
    AC4080
    AC4080

    S
    S
    X
    X
    X
    4.0 V or 13100 digital count

    Small Foot-print, DIP Plastic Package. Amplified, calibrated with correction of 2nd order sensor error; provided with I2C OR Analog outputs

    Custom                     Acuity provides custom packages for specific user applications. Consult Acuity for more details.
        X = Available Ranges; S = Stocked Ranges
